Specifications
1.Innovational Flake Ice Maker
2.Dry, uniform, clean
3.Beautiful in shape
4.Sanitary and convenient
5.Certification:CE,ISO9001
Fresh flake ice machine application field
1 Concrete cooling project
2 Fishery and aquatic food processing
3 Mine temperature reduction
4 Food processing
5 Artificial sking ground
6 Medical facilities
7 Dye chemical industry
8 Medium and large chain supermarket
9 Fresh preservation and cooling field application
Fresh flake ice machine condition
Electrical require: Full electric system complying,With the general international standard
Standard condilion: Water inlet temp.16ˇăC, Amibenttemp:25ˇăC
Application condilion: Ambient temp.5ˇăC~40ˇăC, water temp. 0.5ˇăC~35ˇăC
Special condition: Ambient temp.-30ˇăC~60ˇăC, water temp.0ˇăC~46ˇăC
Ice thickness: 1.5~2.2mm
Refrigerant: R717,R22 ,R404A,R507A
|
Fresh flake ice machine model and performance parameter |
|
Model |
Capacity |
Refrigeration
Capacity |
Evaporating
Temp. |
Reducer
Power |
Circulating
pump power |
Compressor |
Weight |
|
PBJ-350 |
350kg/d |
1645kcal |
-19ˇăC |
0.18kw |
0.025kw |
2HP |
150kg |
|
PBJ-500 |
500kg/d |
2350kcal |
-20ˇăC |
0.18kw |
0.025kw |
3HP |
150kg |
|
PBJ-750 |
750kg/d |
3525kcal |
-20ˇăC |
0.18kw |
0.025kw |
4HP |
150kg |
|
PBJ-1000 |
1000kg/d |
4700kcal |
-20ˇăC |
0.18kw |
0.025kw |
4HP |
150kg |
|
PBJ-1200 |
1200kg/d |
5640kcal |
-22ˇăC |
0.18kw |
0.025kw |
5HP |
150kg |
|
PBJ-1600 |
1600kg/d |
7520kcal |
-22ˇăC |
0.37kw |
0.03kw |
5HP |
150kg |
|
PBJ-2000 |
2000kg/d |
9400kcal |
-22ˇăC |
0.37kw |
0.03kw |
6HP |
150kg |
|
PBJ-3000 |
2500kg/d |
1175kcal |
-22ˇăC |
0.37kw |
0.03kw |
8HP |
150kg |
|
